The PM 12.5S series offers the perfect combination of lifting capacity and maneuverability. The double connecting rod system allows the crane to perform constant and precise movements. Equipped with a manual control valve block as standard. Equipped with a hydraulic moment limiting device that allows operating in total safety. A Type 1 and 2 Interlock stability system can be installed on this crane model. An LC version is also available, with a hydraulically retractable first boom, which facilitates cumbersome and heavy short-range movements, while also optimizing the loading positions under the column.
In its five configurations, the basic machine can reach a horizontal outreach of 14.95 m and a maximum vertical outreach of 18.25 m. Also available with jib up to two extensions for a maximum horizontal outreach of 17.9 m and a maximum vertical outreach of 20.8 m.
– Cranes equipped with connecting rods on the joints
– manual control valve block as standard and multi-function radio control as an option
– Available in LC version
- 2 Stabilizers STANDARD
- 2 Stabilizers XL
- 4 Stabilizers
Manual pull-out outrigger booms
Sequential arm extension exit
Double connecting rod
Manual flip-up outriggers
Proportional hydraulic control valve block
Multi-function radio control
Air/oil heat exchanger
Hydraulic winch on crane
